Sealing Plugs for operating pressure up to 450 bar
MB 700-070
MB series
Expansion and anchorage of sleeve in hole wall is achieved by pressing the ball into sleeve. The MB series plug is designed for use in base materials of both low to high hardness.
Technical Specification
Min. l3
7.3 mm
Sleeve material
Stainless steel
Ball material
Bearing steel, heat-treated
3D-Data available
Order description
MB 700-070
d1
7.0 mm
l1
7.5 mm
l2 ~
10.05 mm
d2
+0.1
0
7.0 mm
Max. d3
6.4 mm
x ±0.2
0.4 mm
Packaging unit
100 / 1000
MB 700 070_en
